Fall 2015 Product Introductions
SIP Sonde Electronics - Complete
electronics, firmware and acquisition and control software
that is suitable for integration into a customer's sonde /
borehole logging system. SIP stimulus and sensing performed
entirely by SIP Sonde Electronics within the borehole. Modular
electronics design supports application specific focusing
and electrode arrangements by simply adding modules.
Stimulus Switch Unit - PSIP
accessory for time domain and self potential measurements.
Power and control from PSIP
Stimulus Amplifier Unit - PSIP
accessory for measurements requiring more power than PSIP
SIP Full Switch Unit -
The PSFS is a switching unit designed specifically as an accessory
to the PSIP. The PSFS maintains the driven guards of the PSIP
for optimal signal quality.
Fall 2014 Product Introduction
PSIP is a low-cost high-performance multi-channel geophysical
instrument optimized for laboratory and in situ near surface
SIP, conventional resistivity, time-domain induced polarization
and self-potential measurements.
- Thin Client -
Thin client used in medical, defense, and manufacturing test applications.
FreeScale processor. Runs O&E developed executive or Linux. LCD
and touchsreen controller, USB and 10/100BT interfaces.
Developed custom transmit and receive antennas for medical application.
Also developed the control and human/system interface electronics.
Visible Light and Thermal Imaging -
Developed TI DSP based visible light and thermal cameras. Both still
image and full motion video. Performed application specific image
analysis. Development done in C, C++, C# and DSP assembler.
Motor Control -
Developed TI DSP based high power sensorless brushless DC motor
controllers for military application. Also implemented resolver
feedback versions. Development done in C and C++ and DSP assembler.
Backplane, Switch Fabric, and system manager -
Developed 100BT 16 slot backplane, switch fabric and system manager
for a telecom product. The system manager used PowerPC and Marvell
Galileo chipset. Switch fabric implemented with Broadcom switches.
- Motor Control -
Motor controller for medical application uses Motorola DSP and RISC
processor for medical application. Interfaces include CAN, USB,
